Ruckus Unleashed H320 802.11ac Wave 2 Wi-Fi Indoor Access point and Switch
SKU: H320-U

Ruckus Unleashed H320 802.11ac Wave 2 Wi-Fi Indoor Access point and Switch

SKU: H320-U
£148.74 £178.49 inc. VAT
In Stock
Tags: Ruckus, Access Point, Wireless, Unleashed, Indoor, Hospitality, H320, 802.11ac
Ruckus H320 Datasheet

Wall-Mounted H320 802.11ac Wave 2 Wi-Fi AP and Switch for Dense Client Environments

In hotels, apartment buildings, and other multi-dwelling structures, wireless connectivity can carry a hefty price tag. You need to connect a wide range of wired devices—IPTV set-top boxes, IP phones, networked minibars, and more—while delivering a great wireless experience.

The Ruckus H320 wall-mounted 802.11ac Wave 2 Wi-Fi access point and switch makes it easy to provide superior wired and wireless connectivity to every user and device. Designed for in-room deployments, the H320 can be discretely mounted over standard electrical junction boxes. With two Ethernet ports, it can securely connect IPTV set-tops, IP phones, and other wired devices without unsightly cabling, while delivering blazing-fast Wi-Fi..

Deliver the full range of in-room services while dramatically reducing cabling, installation time, and construction costs.


Great All-In-One

great in-room Wi-Fi and enable converged IP services with 802.11ac Wave 2 speed and a built-in 2-port Gigabit Ethernet switch.

Stunning Wi-Fi Performance

Extends coverage with patented BeamFlex+TM adaptive antenna technology while mitigating interference by utilizing multi-directional antenna patterns.

Multiple Management Options

Manage the H320 from the cloud, with on-premises physical/virtual appliances, or without a controller.

Get Optimal Throughput

ChannelFly dynamic channel technology uses machine learning to automatically find the least congested channels. You always get the highest throughput the band can support.

Serve More Devices

Connect more devices simultaneously with two MU-MIMO spatial streams and concurrent dual-band 2.4/5GHz radios while enhancing non-Wave 2 device performance.

Support More Services

Multiple SSIDs and switch ports help support services such as VoIP, IPTV, and high-speed Internet access and in-room device connectivity.

Existing Switches and Cables

Designed to operate on existing PoE switches and CAT 5e cabling to minimize costly upgrades.

More Than Wi-Fi

Enhance your network with Cloudpath security and management software, SPoT real-time Wi-Fi location engine and analytics software, and SCI network analytics.

Access Point Specification
Radio Chains / Streams 2x2:2 MU-MIMO 1x1:1 SU-MIMO
Antennas Up to 3dBi
Data Rates · 802.11ac: 6.5 to 867Mbps (MCS0 to MCS9, NSS = 1 to 2 for VHT20/40/80) · 802.11n: 6.5 Mbps to 300Mbps (MCS0 to MCS15) · 802.11a/g: 54, 48, 36, 24, 18, 12, 9, 6Mbps · 802.11b: 11, 5.5, 2 and 1 Mbps
2.4GHz 802.11 b/g/n (max rate: 150Mbps)
5GHz 802.11 a/b/g/n/ac (max rate: 867 Mbps) Wave 2, MU-MIMO
Physical Interface - 2 x 10/100 Mbps Base-T 802.3, 802.3u, RJ45 Ethernet access ports. - 1 x 1GbE 802.3, 802.3u, 802.3ab, 802.3af
PoE 802.3af
Power Consumption POE 802.3af
Indoor / Outdoor Rating Indoor
Dimension (W x D x H) 89mm (L) x 136mm (W) x 29mm (H)
Weight 195g
Operating Temperature 0 °C to +40 °C (+32 °F to +104 °F)
Certifications · Wi-Fi CERTIFIED™ a, b, g, n, ac - Passpoint®, Vantage
Zero Config Plug-n-Play Ruckus Unleashed
Wireless Mesh No
