Open Mesh OM2P V2 802.11g/n 150mbps Access Point with External AntennaSKU: OM2PV2
Plasma Cloud has developed firmware to support most of the Open Mesh access point range including the OM2P, OM2P-LC, OM2P-HS, OM5P-AC, MR1750, A40, A60, A42 and A62.
Take a look at our guide to see how to migrate your network settings, including an over the air unlock and reflash process - How to migrate your cloudtrax network to Plasma Cloud
The OM2P V2 802.11n (802.11g compatible) wireless access point is ideally suited for providing robust internet coverage just about anywhere you need to share a connection.
Examples include hotels, apartments, neighbourhoods, coffee shops, shopping malls, campgrounds, and marinas.
With 20dBm power even at the highest speeds and external antenna with standard RP-SMA connector, it provides the the flexibility to work with 3rd-party external antennas. Note that since the antenna is external, it does not work with the ceiling or Ethernet wall jack enclosures. For indoor installations, we recommend the OM2P-LC or OM2P-HS models.. The OM2P-LC is considerably less expensive and the OM2P-HS is up to twice as fast at the same price.
Open-Mesh OMxP series access points are compatible with passive 12-24v PoE. (Note this is not 802.3af PoE compatible, so these access points cannot be powered with standard PoE switches.) Passive POE keeps costs low, reduces heat dissipation and allows for the most compact size possible. We sell a line of PoE injectors and power supplies to power these access points.
|Access Point Specification|
|Antennas||Single External 1x1 (2.4GHz)|
|Data Rates||150 Mbps|
|Processor||400 MHz QCA9331 MIPS 24K|
|Max Recommended Clients||20-50 per AP|
|Physical Interface||2 x 100Mbps|
|PoE||12-24v Passive (non 802.3af)|
|Dimension (W x D x H)||3.75" x 2.75" x 1"|
|Operating Temperature||0-50 C|
|Zero Config Plug-n-Play||Yes|
|Free Cloud Console||Utility recommends you migrate your Open Mesh networks to Plasma Cloud|
|Free Mobile App||Utility recommends you migrate your Open Mesh networks to Plasma Cloud|
Open Mesh makes WiFi smarter and simpler. We help create powerful, easy-to-use wireless networks that automatically spread Internet connections throughout hotels, apartments, retail stores, restaurants, small and medium-sized businesses—and just about anywhere else.
The Open Mesh Series includes everything you need to deploy professional wireless networks across one site or thousands: a modular platform of access points and indoor and outdoor enclosures for easy, professional installation; CloudTrax, a free cloud-based network controller that can manage an unlimited number of access points and networks; and a global suite of power supplies and PoE solutions.
